Descripción
Envíeconsulta
708/600- MP Rodamientos de bolas de contacto angular de una sola fila
Descripción general
Los rodamientos de bolas de contacto angular con dimensiones principales estandarizadas corresponden a DIN 628-1.
Las tolerancias dimensionales y geométricas de los rodamientos estandarizados corresponden a la clase de tolerancia PN a DIN 620-2.
Los mismos códigos de rodamiento 708/600- MP-UO; 708/600- MP-P5 Los rodamientos están disponibles.
Fila única 708 ..- Serie MP con jaula de latón sólida de MP, guiada en pelota; Esta jaula de latón tiene buena resistencia y resistencia al calor que puede mantener la estructura del rodamiento estable a alta velocidad y adaptarse al calor generado por el rodamiento a alta velocidad. No sellado; Este rodamiento podría usarse a temperaturas operativas de –30 grados a +200 grado (la dimensión de su anillo estabilizó hasta 200 grados). Clase de tolerancia (PN). Podría soportar cargas axiales radiales y unidireccionales, que no se engrasan.
Diámetro de diámetro {{0}} mm; Diámetro exterior -730 mm; ancho -42 mm; Mass -38 kg; cr =330 kN; c0r =830 kN; velocidad limitante =1230 1/min; velocidad de referencia 560 1/min.
Presupuesto
| Dimensiones y hojas de datos técnicas | |
| Parte no. | 708/600- MP -Seling Row Angular Contact Bana Roiling |
| Marca | Marca FAG hecha en Alemania/marca SDVV hecha en China |
| Dimensiones principales | 600x730x42 mm |
| d | 600 mm |
| D | 730 mm |
| B | 42 mm |
| RMIN | 3 mm |
| D1 | 677.25 mm |
| Ángulo de contacto | 30 grados |
| Da Min. | 612.4 mm |
| Da Max. | 717.6 mm |
| ra max. | 2.5 mm |
| CR | 330 kN |
| C0r | 830 kN |
| M | 38 kg |
Lista de ventas en caliente de rodamientos
| 540/532 | 52.388x111.125x38.1 |
| 45287/45220 | 53.975x104.775x30.162 |
| HM807049/HM807010 | 53.975x104.775x36.512 |
| 456/452 | 53.975x107.95x32.557 |
| 55212C/55434 | 53.975x109.985x29.251 |
| 539/532 | 53.975x111.125x38.1 |
| 39578/39520 | 53.975x112.712x30.163 |
| 66212/66461 | 53.975x117.475x33.338 |
| 5577/5520 | 53.975x120.251x44.45 |
| 621/612 | 53.975x120.65x41.275 |
| 66584/66520 | 53.975x122.238x33.338 |
| 72212C/72487 | 53.975x123.825x36.512 |
| 72212/72487 | 53.975x123.825x36.512 |
| 557-S/552 | 53.975x123.825x38.1 |
| 65212/65500 | 53.975x127x44.45 |
| 6280/6220 | 53.975x127x50.8 |
| HM911242/HM911210 | 53.975x130.175x36.513 |
| 78214/78537 | 53.975x136.525x36.513 |
| 78214C/78537 | 53.975x136.525x36.513 |
| 636/632 | 53.975x136.525x41.275 |
| L507945/L507910 | 53.975x87.312x18.258 |
| LM806649/LM806610 | 53.975x88.9x19.05 |
| LM806349C/LM806310 | 53.975x88.9x20.241 |
| 33895/33821 | 53.975x95.25x27.783 |
| 389A/382 | 53.975x98.425x21 |
| HM807048/HM807010 | 54.488x104.775x36.512 |
| 6380/6320 | 54.813x135.755x53.975 |
| 466/452 | 54.988x107.95x32.557 |
| 538/532 | 54.988x111.125x38.1 |
| 6381/6320 | 54.988x135.755x53.975 |
| 28970/28919 | 54.996x99.979x24.605 |
| 622A/612 | 55.006x120.65x41.275 |
| 386/382 | 55.474x98.425x21 |
| 466-S/452 | 55.562x107.95x32.557 |
| 5566/5520 | 55.562x120.251x44.45 |
| 72218C/72487 | 55.562x123.825x36.512 |
| 72218/72487 | 55.562x123.825x36.512 |
| HM813840/HM813810 | 55.562x127x36.512 |
| 28680/28621 | 55.562x96.838x24.608 |
| 389/382 | 55.575x98.425x21 |
| 66583/66520 | 55.753x122.238x33.338 |
| X30211M/Y30211M | 55x100x22.75 |
| X33211M/Y33211M | 55x100x35 |
| 622X/612 | 55x120.65x41.275 |
| 475/472 | 55x120x29.794 |
| X30311/Y30311 | 55x120x31.5 |
| X31311M/Y31311M | 55x120x31.5 |
| X32311bm/y32311bm | 55x120x45.5 |
| 557/552 | 55x123.825x38.1 |
| X32011X/Y32011X | 55x90x23 |
| X33011/Y33011 | 55x90x27 |
| X33111/Y33111 | 55x95x30 |
| 385/382 | 55x98.425x21 |
| 45289/45220 | 57.15x104.775x30.162 |
| 6375/6320 | 57.15x135.755x53.975 |
| 78225/78537 | 57.15x136.525x36.513 |
| 78225C/78537 | 57.15x136.525x36.513 |
| 635/632 | 57.15x136.525x41.275 |
| 6455/6420 | 57.15x149.225x53.975 |
| HH814540/HH814510 | 57.15x152.4x53.975 |
| L507949/L507910 | 57.15x87.312x18.258 |
| 28682/28621 | 57.15x96.838x24.608 |
| 387/382 | 57.15x98.425x21 |
| 388A/382 | 57.531x98.425x21 |
| 388xs/382 | 57.981x98.425x21 |
| 3981/3919RB | 58.738x112.712x30.162 |
| 65231/65500 | 58.738x127x44.45 |
| 3978/3919RB | 59.53x112.712x30.162 |
| 65235/65500 | 59.88x127x44.45 |
| 745/742 | 59.931x150.089x44.45 |
| 66589/66520 | 59.972x122.238x33.338 |
| 66586/66520 | 59.977x122.238x33.338 |
| 28980/28919 | 59.977x99.979x24.605 |
| 39236/39412 | 59.987x104.775x21.433 |
| 3977X/3919RB | 59.987x112.712x30.162 |
| 558-S/552 | 59.987x123.825x38.1 |
| HM813839/HM813810 | 59.987x127x36.512 |
| HM911244/HM911210 | 59.987x130.175x34.1 |
| 6391/6320 | 59.987x135.755x53.975 |
| H913840/H913810 | 59.987x146.05x41.275 |
| L812144/L812111 | 60.325x103.213x17.247 |
| 3960/3919RB | 60.325x112.712x36.512 |
| 5582/5520 | 60.325x120.251x44.45 |
| HM212044/HM212010 | 60.325x122.238x38.1 |
| 557A/552 | 60.325x123.825x38.1 |
| HM813841/HM813810 | 60.325x127x36.512 |
| 65237/65500 | 60.325x127x44.45 |
| HM911245/HM911210 | 60.325x130.175x36.513 |
| 6376/6320 | 60.325x135.755x53.975 |
| 78238/78537 | 60.325x136.525x36.513 |
| 78238C/78537 | 60.325x136.525x36.513 |
| 637/632 | 60.325x136.525x41.275 |
| H715332/H715310 | 60.325x139.7x46.038 |
| HH814542/HH814510 | 60.325x152.4x52.705 |
| 9275/9220 | 60.325x161.925x47.625 |
| 28985/28919 | 60.325x99.979x24.605 |
| X33112/Y33112 | 60x100x30 |
| 29580/29520 | 60x107.95x25.4 |
| X30212M/Y30212M | 60x110x23.75 |
| 397/393 | 60x110x27 |
| X32212M/Y32212M | 60x110x29.75 |
| 3977/3919RB | 60x112.712x30.162 |
| 39582A/39520 | 60x112.712x30.163 |
| 5569/5520 | 60x120.251x44.998 |
| 476/472 | 60x120x29.794 |
| 66585/66520 | 60x122.238x33.338 |
| 558X/552 | 60x123.825x38.1 |
| X30312M/Y30312M | 60x130x33.5 |
| X31312M/Y31312M | 60x130x33.5 |
| X32312B/Y32312B | 60x130x48.5 |
| 6361/6320 | 60x135.755x53.975 |
| 746/742 | 60x150.089x44.45 |
| X32012X/Y32012X | 60x95x23 |
| X33012/Y33012 | 60x95x27 |
| 392/393 | 61.912x110x27 |
| 554/552 | 61.912x123.825x38.1 |
| HM813843/HM813810 | 61.912x127x36.512 |
| HM911249/HM911210 | 61.912x130.175x36.513 |
| H715334/H715310 | 61.912x139.7x46.038 |
| H913842/H913810 | 61.912x146.05x41.275 |
| 9178/9120 | 61.912x158.75x55.562 |
| 28990/28919 | 61.976xx99.979x23.813 |
| 28995/28919 | 62.738x99.979x24.605 |
| L910349/L910310 | 63.487x94.976x17 |
| LM110848/LM110811 | 63.5x101.6x25.4 |
| 39250/39412 | 63.5x104.775x21.433 |
| M111048/M111012 | 63.5x107.95x25.398 |
| 29585/29520 | 63.5x107.95x25.4 |
| 390A/393 | 63.5x110x27 |
| 29670/29620 | 63.5x112.712x25.4 |
| 39585/39520 | 63.5x112.712x30.163 |
| 3955/3919RB | 63.5x112.712x36.512 |
| 33251/33461 | 63.5x117.475x30.162 |
| 5552/5520 | 63.5x120.251x52.387 |
| 477/472 | 63.5x120x29.794 |
| HM212046/HM212010 | 63.5x122.238x38.1 |
| 559/552 | 63.5x123.825x38.1 |
| HM813842/HM813810 | 63.5x127x36.512 |
| 565/562 | 63.5x130.048x36.512 |
| 6382/6320 | 63.5x135.755x53.975 |
| 78250/78537 | 63.5x136.525x36.513 |
| 78248C/78537 | 63.5x136.525x36.513 |
| H414235/H414210 | 63.5x136.525x41.275 |
| 639/632 | 63.5x136.525x41.275 |
| H715336/H715310 | 63.5x139.7x46.038 |
| 6475/6420 | 63.5x149.225x53.975 |
| 745-S/742 | 63.5x150.089x44.45 |
| HH914447/HH914412 | 63.5x177.8x57.15 |
| LL510749/LL510710 | 63.5x92.075x13.495 |
| L610549/L610510 | 63.5x94.458x19.05 |
| 569/562 | 64.963x130.048x36.512 |
| 6464/6420 | 64.96x149.225x53.975 |
| 747-S/742 | 64.96x150.089x44.45 |
| 656/652 | 64.96x152.4x41.275 |
| 396-S/393 | 64.973x110x27 |
| 6385/6320 | 64.973x135.755x53.975 |
| 29588/29520 | 64.988x107.95x25.4 |
| 39586/39520 | 64.988x112.712x30.163 |
| 478xa/472 | 64.988x120x29.794 |
| 78255X/78537 | 64.988x136.525x36.513 |
| LM281049/LM281010 | 646.112x857.25x141.288 |
| 39252X/39412 | 64x104.775x21.433 |
| 6377/6320 | 65.088x135.755x63.5 |
| H715340/H715310 | 65.088x139.7x46.038 |
| 5595/5520 | 65.883x120.251x44.45 |
| H212749/H212710 | 65.987x123.975x41.5 |
| X32013X/Y32013X | 65x100x23 |
| X33013/Y33013 | 65x100x27 |
| 399/393 | 65x110x27 |
| X33113/Y33113 | 65x110x34 |
| X30213M/Y30213M | 65x120x24.75 |
| 478/472 | 65x120x29.794 |
| X32213/YAA32213 | 65x120x32.75 |
| X33213M/Y33213M | 65x120x41 |
| 6385-S/6320 | 65x135.755x53.975 |
| X30313/Y30313 | 65x140x36 |
| X31313M/Y31313M | 65x140x36 |
| X32313M/Y32313M | 65x140x51 |
| 39590A/39520 | 66.65x112.712x30.163 |
| L812147/L812111 | 66.675x103.213x17.247 |
| 29590/29520 | 66.675x107.95x25.4 |
| 395A/393 | 66.675x110x27 |
| 3984/3919RB | 66.675x112.712x30.162 |
| 39589/39520 | 66.675x112.712x30.163 |
| 33261/33461 | 66.675x117.475x30.162 |
| 478-S/472 | 66.675x120x29.794 |
| HM212049/HM212010 | 66.675x122.238x38.1 |
| 560/552 | 66.675x123.825x38.1 |
| HM813844/HM813810 | 66.675x127x36.512 |
| 495AA/492A | 66.675x133.35x30.163 |
| 6386/6320 | 66.675x135.755x53.975 |
| H414242/H414210 | 66.675x136.525x41.275 |
| 641/632 | 66.675x136.525x41.275 |
| H715341/H715310 | 66.675x139.7x46.038 |
| HH814547/HH814510 | 66.675x152.4x53.975 |
| HH914449/HH914412 | 66.675x177.8x57.15 |
| L713049/L713010 | 69.85x101.6x19.05 |
| LM613449/LM613410 | 69.85x112.712x22.225 |
| 29675/29620 | 69.85x112.712x25.4 |
| 33275/33461 | 69.85x117.475x30.162 |
| 482/472 | 69.85x120x29.794 |
| 47487/47420 | 69.85x120x32.545 |
| HM813846/HM813810 | 69.85x127x36.512 |
| 566/562 | 69.85x130.048x36.512 |
| 643/632 | 69.85x136.525x41.275 |
| H715344/H715310 | 69.85x139.7x46.038 |
| HM914545/HM914510 | 69.85x146.05x36.512 |
| H913849/H913810 | 69.85x146.05x41.275 |
| 6454/6420 | 69.85x149.225x53.975 |
| 744A/742 | 69.85x150.089x44.45 |
| 655/652 | 69.85x152.4x41.275 |
| 835/832 | 69.85x168.275x53.975 |
